Configuration parameters
|
Extended Range
|
Pure Electric
|
Basic Parameters
|
Availability
|
2025
|
2024.09-2024.12
|
level
|
Medium and large cars
|
Medium and large cars
|
Energy Type
|
Extended Range
|
Pure Electric
|
Environmental standards
|
National VI
|
-
|
CLTC pure electric cruising range (km)
|
235
|
555-650
|
Battery fast charging time (hours)
|
0.5
|
0.43
|
Battery fast charge capacity range (%)
|
30-80
|
30-80
|
Maximum power (kW)
|
160
|
160-200
|
Maximum torque (N·m)
|
310
|
310-320
|
Gearbox
|
Electric vehicle single speed gearbox
|
Electric vehicle single speed gearbox
|
Body structure
|
5-door 5-passenger hatchback
|
5-door 5-passenger hatchback
|
Length, width and height (mm)
|
4935*1915*1495
|
4935*1915*1495
|
Wheelbase(mm)
|
2915
|
2915
|
Curb weight(kg)
|
1810
|
1730-1835
|
Maximum full load mass (kg)
|
2185
|
2105-2210
|
Body
|
Number of doors
|
5
|
5
|
Number of seats
|
5
|
5
|
Trunk volume (L)
|
541-1303
|
541-1303
|
Drag coefficient (Cd)
|
0.191
|
0.191
|
Electric Motor
|
Total motor power (kW)
|
160
|
160-200
|
Total motor horsepower (Ps)
|
218
|
218-272
|
Total torque of the motor (N·m)
|
310
|
310-320
|
Number of drive motors
|
Single motor
|
Single motor
|
Motor layout
|
Post
|
Post
|
Battery / Charging
|
Battery Type
|
Lithium iron phosphate battery
|
Lithium iron phosphate battery
|
Battery energy (kWh)
|
28.4
|
56.8-70.26
|
Power consumption per 100 km (kWh/100km)
|
12.3
|
11.9-12.4
|
Warranty policy for first-time owners of Sandian
|
No age limit for the first owner (non-operating) / annual mileage not exceeding 30,000 kilometers
|
No age limit for the first owner (non-operating) / annual mileage not exceeding 30,000 kilometers
|
Fast charging port location
|
Right rear side of the car
|
Left rear side of the car
|
Slow charging port location
|
Right rear side of the car
|
Left rear side of the car
|
External AC discharge power (kW)
|
3.3
|
3.3
|
Transmission
|
Number of gears
|
1
|
1
|
Gearbox Type
|
Fixed gear ratio gearbox
|
Fixed gear ratio gearbox
|
Chassis steering
|
|
|
Drive mode
|
Rear-engine, rear-wheel drive
|
Rear-engine, rear-wheel drive
|
Front suspension type
|
McPherson independent suspension
|
McPherson independent suspension
|
Rear suspension type
|
Five-link independent suspension
|
Five-link independent suspension
|
Power type
|
Electric power assist
|
Electric power assist
|
Wheel brakes
|
Front brake type
|
Ventilated disc
|
Ventilated disc
|
Rear brake type
|
Disc
|
Disc
|
Parking brake type
|
Electronic parking brake
|
Electronic parking brake
|
Tire specifications
|
235/45 R19
|
235/50 R18-235/40 R20
|
Passive safety
|
Driver/passenger airbag
|
Primary/Secondary
|
Primary/Secondary
|
Front/rear side airbags
|
Front/Back -
|
Front/Back -
|
Front/rear head airbags (curtain airbags)
|
Front/Back
|
-
|
Active safety
|
ABS anti-lock braking system
|
Standard
|
Standard
|
Braking force distribution (EBD/CBC, etc.)
|
Standard
|
Standard
|
Brake assist (EBA/BAS/BA, etc.)
|
Standard
|
Standard
|
Traction control (ASR/TCS/TRC, etc.)
|
Standard
|
Standard
|
Vehicle stability control (ESC/ESP/DSC, etc.)
|
Standard
|
Standard
|
Tire pressure monitoring function
|
Tire pressure display
|
Tire pressure display
|
Driving control
|
Driving mode switch
|
Sport, Economy, Standard/Comfort
|
Sport, Economy, Standard/Comfort
|
Energy recovery system
|
Standard
|
Standard
|
Automatic parking
|
Standard
|
Standard
|
Hill start assist
|
Standard
|
Standard
|
Driving Hardware
|
|
|
Front/rear parking radar
|
Front/Back
|
Front / Rear
|
Driving assistance images
|
360-degree panoramic images
|
Reversing image, 360-degree panoramic image
|
Number of cameras
|
5
|
1-6
|
Number of ultrasonic radars
|
8
|
4-8
|
Millimeter wave radar quantity
|
2
|
-
|
Driving Features
|
Cruise control system
|
Full-speed adaptive cruise control
|
-
|
Driver Assistance Systems
|
Star Sea Pilot
|
Star Sea Pilot
|
Driving assistance level
|
L2
|
L2
|
Appearance / anti-theft
|
Rim material
|
Aluminum Alloy
|
Aluminum Alloy
|
Key Type
|
Remote control key, Bluetooth key
|
Mechanical key, remote control key, Bluetooth key
|
Keyless start system
|
Standard
|
Standard
|
Keyless entry function
|
Standard
|
Standard
|
Exterior lighting
|
|
|
Low beam light source
|
led
|
led
|
High beam light source
|
led
|
led
|
LED daytime running lights
|
Standard
|
Standard
|
Skylight / Glass
|
Skylight Type
|
Panoramic sunroof cannot be opened
|
Panoramic sunroof cannot be opened
|
Front/rear electric windows
|
Front/Back
|
Front/Back
|
One-touch window lifting function
|
Full vehicle
|
Full vehicle
|
Exterior mirrors
|
Exterior mirror function
|
Electric adjustment, electric folding, heated rearview mirrors, automatic folding when locking the car, rearview mirror memory, automatic folding when reversing
|
Electric adjustment, electric folding, heated rearview mirrors, automatic folding when the car is locked
|
Screen / System
|
Central control color screen
|
Touch LCD screen
|
Touch LCD screen
|
Central control screen size
|
15.6 inches
|
14.6-15.6 inches
|
Voice recognition control system
|
Multimedia system, navigation, telephone, air conditioning, windows, seat heating, seat ventilation
|
Multimedia system, navigation, telephone, air conditioning, windows
|
Voice assistant wake-up word
|
Hello, Fengxing
|
Fengxing, Fengxing, hello, Fengxing
|
In-vehicle intelligent system
|
Xinghai OS
|
Xinghai OS
|
Intelligent Configuration
|
Internet of Vehicles
|
4G network
|
4G/5G Network
|
OTA Update
|
Standard
|
Standard
|
Wi-Fi hotspots
|
Standard
|
Standard
|
Mobile APP remote function
|
Door control, window control, vehicle start, air conditioning control, seat heating, seat ventilation, vehicle condition query/diagnosis
|
Door control, window control, vehicle start, air conditioning control, vehicle condition query/diagnosis
|
Steering wheel /interior mirror
|
Steering wheel material
|
Leather
|
Leather
|
Steering wheel position adjustment
|
Manual up and down + front and back adjustment
|
Manual up and down + front and back adjustment
|
Gear shifting
|
Electronic hand-shift gear
|
Electronic hand-shift gear
|
Multi-function steering wheel
|
Standard
|
Standard
|
Interior rearview mirror function
|
Manual anti-glare
|
Manual anti-glare
|
In-car charging
|
Multimedia/charging port
|
USB, Type-C
|
USB, Type-C
|
Mobile phone wireless charging function
|
Front Row
|
Front Row
|
Mobile phone wireless charging power
|
50W
|
50W
|
Seating Configuration
|
Seat Material
|
imitation leather
|
imitation leather
|
Main seat adjustment
|
Front and rear adjustment, backrest adjustment, height adjustment (2-way)
|
Front and rear adjustment, backrest adjustment, height adjustment (2-way)
|
Co-seat adjustment method
|
Front and rear adjustment, backrest adjustment
|
Front and rear adjustment, backrest adjustment
|
Electric adjustment of driver's seat and passenger seat
|
Primary/Secondary
|
Primary/Secondary
|
Front seat functions
|
Heating and ventilation (driver's seat only)
|
Heating and ventilation (driver's seat only)
|
Electric seat memory function
|
Driving seat
|
Driving seat
|
Audio /Interior Lighting
|
Number of speakers
|
12 speakers
|
6 speakers, 12 speakers
|
Interior ambient lighting
|
64 colors
|
Monochrome, 64 colors
|
Air conditioning / refrigerator
|
Air conditioning temperature control method
|
Automatic air conditioning
|
Automatic air conditioning
|
Rear seat air vents
|
Standard
|
Standard
|
Featured Configuration
|
-
|
Discharge to the outside
|
color
|
Appearance Color
|
Red Cloud
|
Cloud Purple
|
Interior Color
|
Sky Dusk Black, Black/Oriental White
|
Sky Dusk Black, Amber Flow Orange, Black/Oriental White
|
